Industrial Wood Pallet Shredder Machine

Best Wood Waste Shredder Recycling Machine Manufacturer in China

The Industrial Wood Pallet Shredder Machine is designed to process waste wooden pallets, scrap timber, wooden crates, and other bulky wood waste into smaller pieces for efficient handling and recycling. Equipped with a heavy-duty shredding system, it helps reduce wood waste volume and prepares the material for further processing.

  • CE SGS BV ISO9001
  • Excellent pre-sales and after-sales service
Get A Free Quote
Front side view of underwater strand pelletizing system

What Materials Can an Industrial Wood Pallet Shredder Process?

HuaZhao Industrial Wood Shredder Machine can be configured for different types of wood waste, depending on the machine design and operating conditions.

Waste Wooden Pallets Shredding

Processes damaged and discarded wooden pallets from warehouses, factories, and logistics centers.

Scrap Timber and Wood Boards Shredding

Reduces wood offcuts, planks, and discarded boards into smaller pieces for further processing.

Wooden Crates and Packaging Shredding

Handles suitable wooden boxes, crates, and industrial packaging waste.

Construction and Demolition Wood Shredding

Processes selected wood waste from construction and renovation projects, subject to material dimensions and contamination levels.

Branches and Other Wood Waste Shredding

Can be configured for certain types of branches and bulky wood waste after evaluating their size, moisture, and feeding requirements.

How HuaZhao Provides Customized Heavy-Duty Wood Waste Shredder Machine Solutions

Custom Double Shaft Design

Industrial waste shredder machine technical drawing and customized design

Custom Capacity  Design

Industrial waste shredder machine engineering drawing with customized structure design

Case Video of Wood Pallet Shredder Machine

Watch our wood shredding and recycling line turn waste wooden pallets into biomass fuel feedstock. An efficient solution for wood waste recycling and resource recovery.

Industrial Wood Shredder For Sale

Hydraulic Swing Arm Shredder for Plastic Recycling

Swing Arm Shredder
HZ Machine
Guangdong, China
It is suitable for PE, PP film woven bags with large output, and especially suitable for raw materials packed by balers without disassembling and cutting off metal wires. The swing-arm shredder will...
HZB1500：Ø457 mm | Outer Size 1400×1570 mm | Inlet Size 800×1290 mm | 90 kW | 74 rpm | 96 blades | 8/10 fixed blades | Screen Ø40–100 mm | Hydraulic 11 kW | 9500 kg | 1500–1800 kg/h
HZBS1500：Ø750 mm | Outer Size 2450×1620 mm | Inlet Size 1500×1490 mm | 2×75 kW | 52 rpm | 96 blades | 8/10 fixed blades | Screen Ø40–100 mm | Hydraulic 11 kW | 16000 kg | 1800–2000 kg/h
View Details Enquiry Now
Double Rotor Shredder Machine

Double Rotor Shredder Machine
HZ Machine
Guangdong, China
The HuaZhao Double Rotor Shredder Machine is designed for high-capacity shredding of waste plastics, rubber, packaging materials, and industrial solid waste, featuring high torque, stable performance,...
HZSD1000：Ø400 mm | 65 rpm | 55×2 kW | 70×2 moving blades | 2×4 fixed blades | Chamber 1000×980 mm | 7500 kg | 1000–1500 kg/h
HZSD1200：Ø460 mm | 60 rpm | 75×2 kW | 80×2 moving blades | 3×4 fixed blades | Chamber 1200×1250 mm | 8800 kg | 1200–2000 kg/h
HZSD1400：Ø460 mm | 60 rpm | 90×2 kW | 98×2 moving blades | 4×4 fixed blades | Chamber 1400×1250 mm | 10200 kg | 2000–3000 kg/h
View Details Enquiry Now
Single Shaft Shredder Machine for Plastic Waste Recycling

Single Shaft Shredder
HZ Machine
Guangdong, China
Suitable for crushing PP, PE, PET, PC, ABS, plastic lumps, plastic films, electronic waste, aluminum cans, plastic building materials, wood, and other recyclable materials.
GSD1000：Ø355/400 mm | Inlet 1450×1000 mm | 72 rpm | 56 moving blades | 4 fixed blades | Screen Ø40–100 mm | 55/75 kW | Hydraulic 4 kW | Push Range 1000 mm | 4900 kg | ≤1000 kg/h
GSD1200：Ø415 mm | Inlet 1450×1200 mm | 72 rpm | 68 moving blades | 4 fixed blades | Screen Ø40–100 mm | 75/90 kW | Hydraulic 5.5 kW | Push Range 1200 mm | 6500 kg | ≤1500 kg/h
View Details Enquiry Now
Heavy Crusher Machine for Plastic Waste Recycling

Heavy Duty Crusher
HZ Machine
Guangdong, China
The Heavy Duty Crusher is designed for efficient crushing of large and hard plastic materials, featuring high output capacity, stable performance, low energy consumption, and durable blades for heavy-...
PCS800：Ø580×800 mm | 37/45 kW | 2×3/2×5 moving blades | 2×2 fixed blades | Feed Opening 600×1000 mm | Screen Ø12–100 mm | Electric1.1 kW
PJS1000：Ø580×1000 mm | 55/75 kW | 2×3/2×5 moving blades | 2×2 fixed blades | Feed Opening 600×1200 mm | Screen Ø12–100 mm | 1.1 kW
PJS1200：Ø680×1200 mm | 90/110 kW | 2×3/2×5 moving blades | 2×2 fixed blades | Feed Opening 600×1200 mm | Screen Ø12–100 mm | 1.1 kW
View Details Enquiry Now
Large Diameter Pipe Crusher for HDPE and PVC Pipes

Large Diameter Pipe Crusher
HZ Machine
Guangdong, China
The Large Diameter Pipe Crusher is specially designed for crushing large plastic pipes, profiles, and thick-wall materials, featuring high crushing efficiency, stable operation, strong cutting force,...
GSDP600/600：Ø600×600 mm | 30/45 kW | 2×3/2×5 moving blades | 4 fixed blades | Screen Ø12 mm | Hydraulic Drive
GSDP400/500：Ø400×500 mm | 15 kW | 2×3 moving blades | 4 fixed blades | Screen Ø12 mm | Handle Drive
View Details Enquiry Now

Specifications for Industrial Wood Shredder

ItemUnitHZ-DD800HZ-DD1000HZ-DD1200HZ-DD1400
Motor PowerkW45×255×275×290×2
Spindle Rotary DiametermmΦ400Φ400Φ460Φ460
Speedrpm65656060
Number of Moving Bladespcs56×270×280×298×2
Number of Fixed Bladespcs2×42×43×44×4
Shredding Chamber Dimensionmm800×9801000×9801200×12501400×1250
Production Capacitykg/h800-12001000-15001200-20002000-3000
Weightkg58007500880010200

Welcome to HuaZhao Factory

Professional Wooden Shredder Machines Manufacturer

Common Questions About Industrial Waste Wood Shredder Machine

Q: What materials can a waste wood shredder machine process?

A:

A waste wood shredder can process wooden pallets, scrap timber, wood boards, wooden crates, and other suitable wood waste, depending on the machine configuration.

Q: Can shredded wood be used for biomass fuel production?

A:

Yes. Shredded wood can be used as feedstock for biomass fuel production. Additional screening, secondary crushing, or drying may be required to meet the final fuel specifications.

Q: Can a Magnetic Separator Be Added to a Waste Wood Shredding Line?

A:

Yes. A magnetic separator can be integrated into the waste wood shredding line to remove ferrous metal contaminants, such as iron nails and screws, from shredded wood. It helps improve material cleanliness, protect downstream equipment, and prepare wood chips for further processing into biomass fuel. The magnetic separator can be installed above or along the discharge conveyor, depending on the material flow and line configuration.

Q: Can a waste wood shredder process wooden pallets with nails?

A:

Depending on the machine design, it may process pallets containing nails and metal fasteners. Material inspection and appropriate metal separation are recommended to protect downstream equipment and improve material quality.

Q: What determines the processing capacity of a waste wood shredder?

A:

Yes. Aluminum profiles and extrusion scrap can be processed with an industrial shredder. A high-torque drive system provides the cutting force required for bulky and long aluminum profiles.

Q: Can the waste wood shredder be integrated into a complete recycling line?

A:

Yes. It can be integrated with feeding conveyors, magnetic separators, screening equipment, secondary crushers, and other auxiliary equipment to form a customized wood recycling line.

Q: What output size can a waste wood shredder produce?

A:

The output size depends on the cutting system, machine configuration, and material characteristics. Secondary crushing and screening can be added when a smaller or more uniform particle size is required.

Q: How do I choose the right waste wood shredder machine?

A:

Consider the type and dimensions of your wood waste, required processing capacity, target output size, and intended application. Send HuaZhao Machinery material photos or videos for a suitable equipment recommendation.
